ERTi-5 titanium weld solid wire
Item : Titanium WELD Solid Wire
TYPE: Solid drawn Titanium Grade 5 welding wire.
DESCRIPTION AND APPLICATION: ER Ti-5. Grade 5 (Ti 6Al4V)y ERTi-5 commonly called “6-4” is a TIG, MIG, and submerged arc filler metal use for welding alloyed Titanium with 6% & Aluminum 4 % .This grade is common in the Titanium fillers due to its relatively low cost and good availability. With its high tensile strengths and good weld ability it can be heat treated to exhibits a higher fatigue, toughness found in petrochemical, aircrafts components, turbine parts and blades. Its corrosion resistance is generally compared to Grade 2 but yield a higher strength.
SPECIFICATIONS ANSI/ AWS A5.16 ERTi-5
WIRE CHEMISTRY (%) & TYPICAL WELD METAL PROPERITES
|
C |
O |
N |
H |
Fe |
Al |
V |
|
<0.05 |
0.12-0.2 |
<0.03 |
<0.015 |
<0.22 |
5.5-6.75 |
3.4-4.5 |
Tensile strength(psi) > 130000 Yield strength(psi)>120000
SUITABLE FOR Titanium grade 12,Grade7,Grade 2,Grade 5
WELDING PARAMETERS/PACKING
|
Diameter(mm) |
Length(mm) |
Package(KG/BOX) |
Pictures |
|
1.6 |
1000 |
5 |
|
|
2.0 |
1000 |
5 |
|
|
2.4 |
1000 |
5 |
|
|
3.2 |
1000 |
5 |
Note:Spooled wire is also available.
